Back-up Exchange 2010

The current version of DPM is not Exchange 2010 aware*. Therefore you can not directly backup Exchange 2010 mailboxes with DPM2007.
For now (as a work around) there is a plug-in available for the Windows 2008 server backup feature that allows you to backup the Exchange 2010 databases. This plug-in is called WSBExchange.exe and is standard installed with Exchange 2010. The plug-in runs as a service (Microsoft Exchange Server Extension for Windows Server Backup), which can be used by Windows server Backup.

This is a basic way to project

• Backups are VSS-based only. You cannot make streaming ESE backups
• Backups are taken on volume level, To backup the database and log files you need to protect the full volume that contains these files.
• Only full backups can be taken
• Log file truncation will occur after a successful full backup.

First you configured Windows 2008 Server Backup locally on the mailbox server.
Then you can configure DPM to protect the backup files of Windows Server Backup on the mailbox server.

This is maybe not the most efficient way to protect your Exchange, but at least  it’s a work around till DPM is Exchange 2010 aware.

More info on protecting Exchange 2010 with Windows server backup:

• Using Windows Server Backup to Back Up and Restore Exchange Data http://technet.microsoft.com/en-us/library/dd876851(EXCHG.140).aspx
• Perform a Backup of Exchange Using Windows Server Backup http://technet.microsoft.com/en-us/library/dd876854(EXCHG.140).aspx
• Restore a Backup of Exchange Using Windows Server Backup: http://technet.microsoft.com/en-us/library/dd876864(EXCHG.140).aspx

*For Exchange 2010 TAP customers there is a special version of DPM2007 available that is Exchange 2010 aware. But this version does not support any other data then Exchange 2010
